ZVM-29083 VEYA 4×4
The ZVM-29083 VEYA 4×4 is an all-wheel-drive amphibious snow-and-swamp vehicle designed to transport people, equipment, and cargo across swamps, snow, peat bogs, sand, and cross-country terrain.
The updated model combines the high mobility of a specialized off-road vehicle, a spacious insulated body, and the comfort of a car. It is designed for operation in difficult climatic and road conditions.
1. Mobility That Opens New Routes
At the heart of VEYA are design solutions for confident movement over weak-bearing soils and difficult terrain.
Full-Time 4×4 Drive
Drive to the front and rear axles for movement over difficult sections.
Portal Axles
With original wheel reduction gears — high ground clearance and efficient traction transmission.
Low-Pressure Tyres
Size 1300×700 mm — increased contact patch and reduced specific ground pressure.
Ground Clearance 600 mm
Ability to overcome deep ruts, irregularities, and obstacles.
VEYA is designed for operation on snow, swamps, peat bogs, sand, and soft soils.
2. VEYA — An Amphibious Off-Road Vehicle
Water obstacles do not necessarily become an obstacle to the route.
The design of VEYA allows it to overcome water areas, expanding operating capabilities in swampy territories, areas of seasonal flooding, and remote facilities.
This is especially important for expedition teams, industrial enterprises, and rescue units operating far from road infrastructure.
3. Strength in Thoughtful Design
The design of the off-road vehicle is developed with consideration for operation under increased loads and difficult off-road conditions.
Main design features:
- Ladder-type steel frame.
- Portal axles with original wheel reduction gears.
- Full-time drive to the front and rear axles.
- Lockable differential connection.
- Wheel rims with clamping rings.
- Low-pressure tyres 1300×700 mm.
The combination of these solutions ensures high ground clearance, necessary traction, and mobility on weak-bearing soils.
4. Power and Transmission for Difficult Conditions
The ZVM-29083 is equipped with a ZMZ PRO petrol engine or a GAZ G31C diesel engine with a power output of 149.6 hp.
The power unit works in tandem with a 6-speed manual gearbox and a 2-speed transfer case.
Transmission features:
- Mechanical 6-speed synchronized gearbox.
- 2-speed mechanical transfer case.
- Lockable symmetrical inter-axle differential.
- Hypoid final drive.
- Single-stage reduction wheel gears.
Two engine options allow you to choose the version based on operating conditions and specifics.
5. Comfort That Doesn't End with the Road
VEYA is a full-fledged vehicle for transporting the crew in a protected cabin.
The all-metal three-door body with a roof hatch is insulated and designed for year-round operation. Capacity — from 2 to 8 people, depending on the version.
Standard equipment includes:
- Climate control.
- Additional liquid heater for the passenger cabin.
- Suspended driver's seat.
- Electric heating of the windshield and side mirrors.
- Heated driver's seat and steering wheel.
- Power windows for the front doors.
- Multimedia system.
- Driver and front passenger airbags.
- Cargo compartment with lockers for equipment and belongings.
For the diesel version, an autonomous liquid engine preheater is provided.
6. Capacity and Payload
VEYA is designed not only for transporting passengers but also for delivering equipment, tools, and necessary gear.
- Number of seats: 2–8.
- Payload on firm ground: up to 700 kg.
- Payload on weak-bearing soils and afloat: up to 400 kg.
- Curb weight: 3,200 kg.
- Maximum permissible weight: 3,900 kg on firm ground.
The spacious cabin and cargo compartment allow the vehicle to be used for transporting personnel and necessary equipment to remote facilities.
7. Equipment for Your Tasks
VEYA can be additionally equipped with equipment based on operating conditions and the specifics of the tasks performed.
Available options:
- Electric winch.
- Central tyre inflation system.
- Autonomous cabin heater.
- Searchlight.
- Roof rack.
- Bull bar with branch guards.
- Snorkel.
- GLONASS/GPS satellite navigation.
- Electric heating of the fuel intake.
- Fuel filter with electric fuel heating.
- Custom body color painting.
The composition of additional equipment is selected for specific operating conditions and customer requirements.
8. Applications
ZVM-29083 VEYA is suitable for solving transport tasks in various industries:
- Oil and gas industry — delivery of personnel, tools, and equipment to remote facilities.
- Geological exploration and expeditions — transportation of research teams across hard-to-reach territories.
- Emergency and rescue services — access to flooded, swampy, and remote areas.
- Forestry and environmental management — patrolling and servicing remote territories.
- Tourism and expedition projects — transportation of passengers along routes without road infrastructure.
- Private and commercial use — servicing country properties, hunting, fishing, and cargo transport.
9. Technical Specifications
| Model | ZVM-29083 |
| Wheel arrangement | 4×4 |
| Vehicle type | Amphibious snow-and-swamp vehicle |
| Engine | ZMZ PRO / GAZ G31C |
| Power | 149.6 hp |
| Gearbox | Manual, 6-speed |
| Tyres | 1300×700 mm |
| Ground clearance | 600 mm |
| Number of seats | 2–8 |
| Payload on firm ground | Up to 700 kg |
| Payload on weak-bearing soils and afloat | Up to 400 kg |
| Curb weight | 3,200 kg |
| Maximum weight | 3,900 kg |
Configuration Selection
We will select the ZVM-29083 VEYA version and additional equipment based on operating conditions, number of passengers, payload requirements, and the specifics of your tasks.
Request a commercial proposal for the ZVM-29083 VEYA 4×4.
Zavod Vezdekhodnykh Mashin specialists will advise you on configurations, technical capabilities, and delivery terms.
Photo and Video
ZVM-29083 VEYA 4×4
The ZVM-29083 VEYA 4×4 is an all-wheel-drive amphibious snow-and-swamp vehicle designed to transport people, equipment, and cargo across swamps, snow, peat bogs, sand, and cross-country terrain.
The updated model combines the high mobility of a specialized off-road vehicle, a spacious insulated body, and the comfort of a car. It is designed for operation in difficult climatic and road conditions.
1. Mobility That Opens New Routes
At the heart of VEYA are design solutions for confident movement over weak-bearing soils and difficult terrain.
Full-Time 4×4 Drive
Drive to the front and rear axles for movement over difficult sections.
Portal Axles
With original wheel reduction gears — high ground clearance and efficient traction transmission.
Low-Pressure Tyres
Size 1300×700 mm — increased contact patch and reduced specific ground pressure.
Ground Clearance 600 mm
Ability to overcome deep ruts, irregularities, and obstacles.
VEYA is designed for operation on snow, swamps, peat bogs, sand, and soft soils.
2. VEYA — An Amphibious Off-Road Vehicle
Water obstacles do not necessarily become an obstacle to the route.
The design of VEYA allows it to overcome water areas, expanding operating capabilities in swampy territories, areas of seasonal flooding, and remote facilities.
This is especially important for expedition teams, industrial enterprises, and rescue units operating far from road infrastructure.
3. Strength in Thoughtful Design
The design of the off-road vehicle is developed with consideration for operation under increased loads and difficult off-road conditions.
Main design features:
- Ladder-type steel frame.
- Portal axles with original wheel reduction gears.
- Full-time drive to the front and rear axles.
- Lockable differential connection.
- Wheel rims with clamping rings.
- Low-pressure tyres 1300×700 mm.
The combination of these solutions ensures high ground clearance, necessary traction, and mobility on weak-bearing soils.
4. Power and Transmission for Difficult Conditions
The ZVM-29083 is equipped with a ZMZ PRO petrol engine or a GAZ G31C diesel engine with a power output of 149.6 hp.
The power unit works in tandem with a 6-speed manual gearbox and a 2-speed transfer case.
Transmission features:
- Mechanical 6-speed synchronized gearbox.
- 2-speed mechanical transfer case.
- Lockable symmetrical inter-axle differential.
- Hypoid final drive.
- Single-stage reduction wheel gears.
Two engine options allow you to choose the version based on operating conditions and specifics.
5. Comfort That Doesn't End with the Road
VEYA is a full-fledged vehicle for transporting the crew in a protected cabin.
The all-metal three-door body with a roof hatch is insulated and designed for year-round operation. Capacity — from 2 to 8 people, depending on the version.
Standard equipment includes:
- Climate control.
- Additional liquid heater for the passenger cabin.
- Suspended driver's seat.
- Electric heating of the windshield and side mirrors.
- Heated driver's seat and steering wheel.
- Power windows for the front doors.
- Multimedia system.
- Driver and front passenger airbags.
- Cargo compartment with lockers for equipment and belongings.
For the diesel version, an autonomous liquid engine preheater is provided.
6. Capacity and Payload
VEYA is designed not only for transporting passengers but also for delivering equipment, tools, and necessary gear.
- Number of seats: 2–8.
- Payload on firm ground: up to 700 kg.
- Payload on weak-bearing soils and afloat: up to 400 kg.
- Curb weight: 3,200 kg.
- Maximum permissible weight: 3,900 kg on firm ground.
The spacious cabin and cargo compartment allow the vehicle to be used for transporting personnel and necessary equipment to remote facilities.
7. Equipment for Your Tasks
VEYA can be additionally equipped with equipment based on operating conditions and the specifics of the tasks performed.
Available options:
- Electric winch.
- Central tyre inflation system.
- Autonomous cabin heater.
- Searchlight.
- Roof rack.
- Bull bar with branch guards.
- Snorkel.
- GLONASS/GPS satellite navigation.
- Electric heating of the fuel intake.
- Fuel filter with electric fuel heating.
- Custom body color painting.
The composition of additional equipment is selected for specific operating conditions and customer requirements.
8. Applications
ZVM-29083 VEYA is suitable for solving transport tasks in various industries:
- Oil and gas industry — delivery of personnel, tools, and equipment to remote facilities.
- Geological exploration and expeditions — transportation of research teams across hard-to-reach territories.
- Emergency and rescue services — access to flooded, swampy, and remote areas.
- Forestry and environmental management — patrolling and servicing remote territories.
- Tourism and expedition projects — transportation of passengers along routes without road infrastructure.
- Private and commercial use — servicing country properties, hunting, fishing, and cargo transport.
9. Technical Specifications
| Model | ZVM-29083 |
| Wheel arrangement | 4×4 |
| Vehicle type | Amphibious snow-and-swamp vehicle |
| Engine | ZMZ PRO / GAZ G31C |
| Power | 149.6 hp |
| Gearbox | Manual, 6-speed |
| Tyres | 1300×700 mm |
| Ground clearance | 600 mm |
| Number of seats | 2–8 |
| Payload on firm ground | Up to 700 kg |
| Payload on weak-bearing soils and afloat | Up to 400 kg |
| Curb weight | 3,200 kg |
| Maximum weight | 3,900 kg |
Configuration Selection
We will select the ZVM-29083 VEYA version and additional equipment based on operating conditions, number of passengers, payload requirements, and the specifics of your tasks.
Request a commercial proposal for the ZVM-29083 VEYA 4×4.
Zavod Vezdekhodnykh Mashin specialists will advise you on configurations, technical capabilities, and delivery terms.
Specifications
| Modifications | ZVM-29083 4×4 with portal axles |
|---|---|
| General Data | |
| Designation | ZVM-29083 |
| Wheel arrangement | 4×4 |
| Curb weight, kg | 3,200 |
| Maximum permissible weight / payload capacity | |
| — on firm ground, kg | 3,900 / 700 |
| — on weak-bearing soils and afloat, kg | 3,600 / 400 |
| Wheelbase (to rear axle) / track / ground clearance, mm | 3,400 / 1,800 / 600 |
| Overall dimensions: length / width / height, mm | 5,750 / 2,540 / 3,100 |
| Body | |
| Body type | All-metal 3-door with roof hatch |
| Number of seats in the cabin, including driver (available configurations) | 2–8 |
| Engine | |
| Petrol: ZMZ PRO (ZMZ 409051.10 or 409052.10) | 149.6 hp |
| Diesel: GAZ G31C | 149.6 hp |
| Transmission | |
| Clutch | Single-plate, dry-friction, hydraulically operated |
| Gearbox | Mechanical 6-speed synchronized |
| Transfer case | Mechanical 2-speed with lockable symmetrical bevel inter-axle differential |
| Final drive | Bevel, hypoid with symmetrical bevel differential |
| Wheel hub reduction gear | Mechanical single-stage reduction gear |
