ZVM-39083 VEYA 6×6
The ZVM-39083 VEYA 6×6 is an all-wheel-drive amphibious off-road vehicle designed to transport people, equipment, and cargo over difficult terrain. Three axles, portal axles, and low-pressure tyres help overcome challenging route sections, while a spacious all-metal body allows the vehicle to be used for industrial, expedition, and special tasks.
1. Six Wheels — More Capability Off-Road
The 6×6 wheel configuration gives the vehicle additional support on the ground and helps distribute the load between the axles.
The transmission design provides drive to the front and middle axles with a lockable inter-axle differential, as well as a connectable rear-axle drive. This allows the vehicle's traction capabilities to be used according to road conditions and route specifics.
VEYA is designed for movement over snow, swamps, peat bogs, sand, and cross-country terrain — where conventional wheeled machinery loses mobility.
2. Low-Pressure Tyres — Movement Over Weak Soils
VEYA is equipped with low-pressure tyres sized 1300×700 mm.
The large contact area between the wheels and the surface helps distribute the load and reduce specific ground pressure. This reduces the risk of sinking and allows the vehicle to move over areas where conventional wheeled machinery faces serious limitations.
Such tyres are especially valuable for work on swampy areas, virgin snow, peat bogs, and sandy soils.
3. VEYA — An Amphibious Off-Road Vehicle
Water obstacles do not necessarily mean the end of the route. VEYA belongs to the class of amphibious off-road vehicles and is capable of moving on water.
This expands operating capabilities in areas with rivers, lakes, swampy territories, and flooded sections. The speed afloat is 2–3 km/h with additional equipment.
4. Reinforced Frame and Portal Axles
At the heart of the vehicle is a steel ladder-type frame designed for operation in difficult road conditions.
Portal axles with original wheel reduction gears provide a ground clearance of 600 mm. This design helps overcome deep ruts, terrain irregularities, and other obstacles.
The wheel reduction gears are made as removable units, which accounts for the vehicle's maintenance and repair requirements.
5. Power and Transmission for Difficult Conditions
VEYA can be equipped with a petrol or diesel engine with a power output of 149.6 hp.
Engine options:
- petrol ZMZ PRO;
- diesel GAZ G31C.
The engine works in tandem with a 6-speed manual gearbox and a 2-speed transfer case. The inter-axle differential of the front and middle axle drive has a lock, and the rear axle is connected when needed.
This combination allows the driving mode to be selected according to the terrain, surface, and vehicle load.
6. Spacious Body for Crew and Equipment
Depending on the version, VEYA is designed to accommodate from 2 to 10 people.
The all-metal welded three-door body with a roof hatch is suitable for passenger and passenger-and-cargo use. Cabin insulation and additional heating equipment help maintain comfortable conditions during cold-weather operation.
The cargo compartment has storage lockers for belongings and necessary equipment.
7. Payload for Industrial Tasks
The three-axle layout allows transporting not only a work crew but also equipment, tools, and necessary cargo.
Payload depends on the surface type:
- up to 1,000 kg — on firm ground;
- up to 500 kg — on weak-bearing soils and afloat.
This allows personnel and equipment to be delivered to remote facilities without involving additional transport for work cargo.
8. Comfort and Equipment for Operating Conditions
The standard VEYA configuration includes equipment for comfortable crew operation:
- autonomous liquid engine preheater for diesel versions;
- additional liquid passenger cabin heater;
- driver's seat with suspension system;
- climate control;
- roof hatch;
- multimedia system;
- driver and front passenger airbags;
- electric heating of the windshield and side mirrors;
- electric heating of the driver's seat and steering wheel;
- power windows for the front doors;
- tilt-adjustable steering column;
- cabin insulation;
- storage lockers in the cargo compartment.
Optional equipment available:
- electric winch;
- central tyre inflation system;
- autonomous cabin heater;
- searchlight;
- roof rack;
- bull bar with branch guards;
- air intake (snorkel);
- GLONASS/GPS satellite navigation equipment;
- fuel system heating equipment.
The configuration is selected according to the vehicle's purpose and operating conditions.
9. Applications
ZVM-39083 VEYA 6×6 is suitable for tasks that require delivering personnel, equipment, and cargo along routes without road infrastructure.
Oil, Gas, and Energy Industries
Delivery of personnel and equipment to remote facilities.
Geological Exploration and Expeditions
Transportation of research teams across hard-to-reach territories.
Servicing Remote Facilities
Regular trips to production sites outside the road network.
Forestry and Agriculture
Work in areas where conventional machinery cannot pass.
Environmental Organizations and Nature Reserves
Patrolling and monitoring of hard-to-reach territories.
Search-and-Rescue and Emergency Services
Access to areas cut off from the road network.
10. Technical Specifications
| Model | ZVM-39083 VEYA |
| Wheel configuration | 6×6 |
| Vehicle type | Wheeled amphibious off-road vehicle |
| Engine | Petrol ZMZ PRO / diesel GAZ G31C |
| Engine power | 149.6 hp |
| Gearbox | Manual, 6-speed |
| Transfer case | Manual, 2-speed |
| Tyre size | 1300×700 mm |
| Tyre type | Low-pressure |
| Ground clearance | 600 mm |
| Number of seats | 2–10 |
| Maximum permissible weight on firm ground | 4,500 kg |
| Payload on firm ground | up to 1,000 kg |
| Maximum permissible weight on weak-bearing soils and afloat | 3,900 kg |
| Payload on weak-bearing soils and afloat | up to 500 kg |
| Overall dimensions (L×W×H) | 6,150×2,540×3,100 mm |
| Maximum speed on highway | 70 km/h |
| Speed afloat | 2–3 km/h, with additional equipment |
| Gradability at full load | up to 35° |
| Permissible lateral roll without load | up to 20° |
| Minimum turning radius | 9 m |
ZVM-39083 VEYA 6×6 vs. TREKOL VEGA 6×6: Comparing Specifications
Both vehicles belong to the class of three-axle off-road vehicles and are intended for transporting people and cargo off-road. Let us compare the main parameters that help evaluate their capabilities for work in hard-to-reach areas.
| Parameter | ZVM-39083 VEYA | TREKOL VEGA |
|---|---|---|
| Wheel configuration | 6×6 | 6×6 |
| Number of seats | 2–10 | 8 |
| Tyre size | 1300×700 mm | 1300×600 mm |
| Ground clearance | 600 mm | 490 mm |
| Gearbox | Manual, 6-speed | Manual, 5-speed |
| Payload on firm ground | up to 1,000 kg | up to 600 kg |
| Payload on weak-bearing soils | up to 500 kg | up to 400 kg |
What Makes VEYA Stand Out?
According to published specifications, the ZVM-39083 has wider tyres, greater ground clearance, and a higher stated payload. In addition, VEYA accommodates up to 10 people and is equipped with a 6-speed manual gearbox.
TREKOL VEGA is an eight-seat off-road vehicle with an aluminium insulated body. Its design is also focused on year-round transportation of passengers and cargo off-road.
When choosing equipment, it is important to consider not only individual specifications but also route conditions, the number of passengers, the weight of the equipment transported, and equipment requirements.
Configure VEYA for Your Tasks
Tell Zavod Vezdekhodnykh Mashin specialists where you plan to operate the snow-and-swamp vehicle and what tasks it should perform. We will help you select the appropriate configuration, engine, and additional equipment based on your operating conditions.
ZVM-39083 VEYA 6×6 — more capability for work where conventional roads do not go.
国际合作伙伴联系方式
俄罗斯全地形车辆制造厂(ZVM)欢迎与海外企业、经销商及最终客户开展合作。
电话:+7 920 058-28-40
电子邮箱:sales@zvm-nn.ru
微信(WeChat):wxid_dhdqihdmcn5w22
